3-Ply 600# 3/8 x 3/32 Grade 1

3-Ply 600# 3/8 x 3/32 Grade 1

Part# 20241012

High tension belt for handling heavy material, higher tonnages, and large lump sizes. Extra thick Grade 1 cover. Withstands high impact as well as tearing and gouging from sharp/heavy material.



SPECIFICATIONS

  • EAN / UPC: 725559186790
  • Spec#: 14B
  • Ply: 3
  • Working Tension: 600
  • Color: Black
  • Compound: SBR Blend
  • Carcass: Polyester/Nylon
  • Top Surface: Smooth
  • Bottom Surface: Smooth
  • Thickness / Overall Gauge: 0.71875"
  • Weight (PIW): 0.375
  • Elongation @ 100%: 1-2%
  • Minimum Pulley: 24"
  • Temperature Range: -25°F to 225°F
  • Oil Resistant: No
  • Durometer: 60 +/- 5
  • Clipper®: Not Recommended
  • Alligator®: Not Recommended
  • Staple: Not Recommended
  • Solid Plate: 1-1/2
  • Flexco® Bolt On: Not Recommended
  • Flexco® Rivet: R6
  • Endless Splice: Bias Step
